Fire Retardant Connectors
These push-fit connectors are made from Fire Retardant materials and are designed for Buildings where fire protection properties are required. They are made in compliance with BS EN 50411-2-8-2009 and UL94-V0.
Straight connectors are used to join microducts of the same diameter to provide a dedicated link for either pulling or blowing fibre optic cables.
Featuring a transparent body for ease of visual inspection to ensure the tube is inserted correctly.
Removal is easily achieved by pressing the collet inwards. As an option, connectors can be supplied with a tamper-proof locking clip which prevents accidental disconnection.
Features & Benefits
- Fire Retardant for indoor use /buildings
- Push-fit
- Easy connection & disconnection
- Transparent body
- IP68 protection
- 16bar blowing pressure
- 20 years lifetime
- Suitable for a wide range of temperatures
- EN50411-2-8 compliant
- UL94-V0 compliant
Sizes
| Diameter (mm) |
| 5 |
| 6 |
| 7 |
| 8 |
| 10/8 |
| 12/8 |
| Diameter (mm) |
| 12/10 |
| 12/7 |
| 14/10 |
| 14/12 |
| 16/12 |
Other sizes may be available on request and subject to MOQ
Options
- Locking clips
Certification
- EN 50411-2-8 Microduct connector specification
- UL94-V0 Standard for Safety of Flammability of Plastic Materials for Parts in Devices and Appliances testing
